Condition Monitoring
main menu
Vibration Meters & Monitors

ROTOMECH offers most convenieint ,Economic Hand Held/Pocket type Vibration Meter which measures all three parametere Acceleration also with Bearing condition Monitoring , Velocity & Displacemet

Technical -Specifications:( Hand Held Pocket Type Vibration Meter)
Filter baud : D P
Acceleration 10Hz-1KHz 0.1-200m/ms2 20.1-400m/ms2
  10Hz-10KHz 0.3-200ft/ms2 0.3-1312ft/ms2
Velocity 10Hz-1KHz 0.1-8.0inch/s 0.1-400mm/s
    0.004-16.0inch
Displacement 10Hz-1KHz 0.001-2.0mm 0.001-4.0mm
  0.04-80mil 0.04-160 mil
Accuracy : <5%
Auto power off
RPM(revolution) :
Frequency : 0.1 to 10KHz
Metric/imperial conversion
With RS232C interface
Max hold
Power supply : 4x1.5V  AAA(UM-4)battery
Battery indicator : low battery indicator
Dimensions : 124x62x30mm
weight: 120g(not including battery)
Optional accessories : Cable & software for RS-232C.



Pen Type Bearing fault Detector with Enveloping.
Also avaliable with built in IR Temp. Monitor with Yellow / Green / Red LED indicator & built in ISo 10816-2 & 3 group selector

Rotating Machines (Turbine, Power Train, Gearboxes, etc.)
